Sound Generator |
Piano Sound |
SuperNATURAL Piano |
|
Max. Polyphony |
256 |
|
Tones |
Piano: 16 tones |
|
|
E.Piano: 18 tones |
|
|
Organ: 18 tones |
|
|
Strings/Pad: 27 tones |
|
|
Synth/Other: 279 tones (including 8 drum sets, 1 SFX set) |
Ambience |
Type |
Studio, Lounge, Concert Hall, Cathedral |
|
Depth |
11 types |
My Stage |
My Stage |
8 types |
Keyboard |
Keyboard |
88 keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel) |
Speaker System |
Speakers |
8 x 12 cm (3-3/16 x 4-3/4 inches) x 2 (with speaker box) |
|
Rated Power Output |
13 W x 2 |
Headphones |
Headphones |
Headphones 3D Ambience |
Bluetooth |
Audio |
Bluetooth Ver 3.0 (Supports SCMS-T content protection) |
|
MIDI |
Bluetooth Ver 4.0 |
Compatible Android / iOS Apps (Roland) |
Compatible Android / iOS Apps (Roland) |
Piano Every Day |
|
|
Piano Designer |
Data Playback |
Playable Software |
Standard MIDI Files (Format 0, 1) |
|
|
Audio File (WAV: 44.1 kHz, 16-bit linear format, MP3: 44.1 kHz, 64 kbps - 320 kbps, requires USB flash drive) |
Recorder |
Recordable Software |
Standard MIDI Files (Format 0, 3 parts, Approx. 70,000 notes memory) |
|
|
Audio File (WAV: 44.1 kHz, 16-bit linear format, requires USB flash drive) |
|
Internal Songs |
32 Songs |
Tuning, Voicing |
Touch Sensitivity |
Key Touch: 100 types, fixed touch |
|
|
Hammer Response: 10 types |
|
Master Tuning |
415.3--466.2 Hz (adjustable in increments of 0.1 Hz) |
|
Temperament |
10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament key |
|
Effects |
Ambience |
|
|
Equalizer (3-band digital equalizer) |
|
|
Only for organ tones: Rotary Speaker Effect |
|
|
Only for E.Piano tones: Modulation Speed |
|
Mic Effects |
Compressor |
|
|
Doubling |
|
|
Echo |
|
Piano Designer |
Lid |
|
|
String Resonance |
|
|
Damper Resonance |
|
|
Key Off Resonance |
|
|
Single Note Tuning |
|
|
Single Note Volume |
|
|
Single Note Character |
Convenient Functions |
Convenient Functions |
Metronome (adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone) |
|
|
Auto Tempo |
|
|
Transpose (Keyboard/Song: in semitones) |
|
|
Registration (45 registrations, capable of pedal shift) |
|
|
Registration Set |
|
|
Dual |
|
|
Split (split point adjustable) |
|
|
Twin Piano |
|
|
Tone Demo |
|
|
Auto Off |
Other |
Display |
Graphic LCD 132 x 32 dots |
|
Control |
Volume slider |
|
|
Equalizer sliders (Low/Mid/High) |
|
|
Part sliders (Lower/Upper) |
|
|
Mic Vol. slider |
|
|
Speaker switch |
|
|
Mic Gain knob |
|
Connectors |
DC In jack |
|
|
Pedal (Damper/R, Sostenuto/C , Soft/L Power Supply) jacks: TRS 1/4-inch phone type |
|
|
Input Stereo jack: Stereo miniature phone type |
|
|
Output (L/Mono, R) jacks: 1/4-inch phone type |
|
|
Mic Input jack: 1/4-inch phone type |
|
|
USB Computer port: USB B type |
|
|
USB Memory port: USB A type |
|
|
Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type |
|
Power Supply |
AC adaptor |
|
Power Consumption |
25W (When using the included AC adaptor) *Approximate power consumption when playing the piano at medium volume: 5W |
|
|
Power consumption when sound has not been played after power-on: 4W |
Accessories |
Accessories |
Owner's Manual |
|
|
Leaflet "USING THE UNIT SAFELY" |
|
|
AC adaptor |
|
|
Power cord |
|
|
Music rest |
|
|
Damper pedal (DP-10, capable of continuous detection) |
Size & Weight |
Dimensions |
Detached music rest: 1,291 (W) x 344 (D) x 126 (H) mm |
|
Weight |
19.3 kg (FP-60X with music rest) |
